Type

• Scale: 1/10th
• Brushed/Brushless: BL
• Sensored/Sensorless: SD
• Waterproof: Waterproof

Specifications

• Cont./Peak Current: 40A
• Input Voltage: 2-3S LiPo/6-9 Cell NiMH
• BEC Output: 6V/7.4V@4A 6A peak
• Motor KV: 1800KV
• Diameter/Length of Motor: 36mm / 58.1mm
• Shaft Diameter / Exposed Shaft Length: 3.175mm / 16.5mm
• Motor Poles:4

Wires & Connectors

• Input Wires: Red-14AWG-200mm*1 /' Black-14AWG-200mm*1
• Input Connectors: XT60

(Note: All the wire length above is the original length, not the length you see from the outside.)

ESC Programming Via

• SET Button on ESC: Not Supporterd
• LED Program Box: Supported
• LCD Program Box: Not Supported
• OTA Programmer: Not Supported
• Program Port: Independent programming interface (Switch Positionm)

Firmware

Firmware Upgrade: Not Supported

Size & Weight

• Size: 36 x 58.1mm
• Weight: 201g (Including Wires and Connectors)

Applications

• Venicles: 1/10th Rock Crawler
